Dimension |
|
112 mm x 195 mm x 37 mm |
|
Weight |
|
800g |
|
Lock rope length |
|
300 mm (The length can be customized as needed.) |
|
Power supply |
|
DC 9–14 V; 2 A |
|
Material |
|
The outer case of the device adopts PC materials |
|
Backup battery |
|
14000 mAh/3.7 V |
|
Power consumption |
|
Current in standby (sleep) mode: 9 mA
Current in normal working mode: 95 mA |
|
Charging time |
|
7.5–8 hours |
|
Operating temperature |
|
-20°C to 55°C |
|
Operating humidity |
|
5%–95 % |
|
Working hour |
|
Power-saving mode: 78 days
Normal working mode: 150 hours |
|
Charging |
|
Magnetic charging (DC 9 V; 2 A; fast charging) |
|
Water resistance rating |
|
IP67 |
|
Frequency band |
|
K211L-ER:
LTE-FDD: B1/B3/5/B7/B8/B20/B28
GSM: 850/900/1800/1900 MHz |
K211L-AUR:
LTE-FDD: B2/B3/B4/B5/B7/B8/B28/B66
GSM: 850/900/1800/1900 |
K211E:
LTE Cat M1/NB2: B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B71/B85
GSM: 850/900/1800/1900 MHz |
|
GPS antenna |
|
Built-in GPS antenna |
|
GPS sensitivity |
|
-161 dB |
|
Positioning accuracy |
|
2.5 meters |
|
LoRa communication distance (optional) |
|
At most 20 meters (obtained from actual tests in trucks’ containers) |
|
LoRa working frequency (optional) |
|
137–1020 MHz (433 MHz by default) |
|
LoRa antenna (optional) |
|
Built-in spring antenna |
|
RFID module frequency |
|
125 KHz |
|
Memory |
|
64 MB |
|
SIM card installation |
|
Flip the card slot cover to install Micro SIM cards; dual SIM cards |
