Astra Telematics AT111 2G-LTE

Home » GPS Tracker » Astra Telematics AT111 2G-LTE

Our AT111 is ideal for applications where external antennas must be used, either roof-mount, glass-mount, mag-mount or self-adhesive antenna options are availablOur AT111 is ideal for applications where external antennas must be used, either roof-mount, glass-mount, mag-mount or self-adhesive antenna options are available, to suit all possible installation types and vehicles.

INFORMATION
FEATURES

Name	Description
Server Port	5723

AT111

Technical Specifications

Mobile Network Communications	GSM/GPRS(2G) + UMTS(3G)
Minimum Operating Voltage	6.0V
Maximum Operating Voltage	50.0V
Qi Wireless Charging	No
GSM Antenna	External
GNSS Antenna Type	External
GNSS Antenna Size	25mm
BLE (Bluetooth)	No
SIM Card Format	Micro
Tamper Sensor	No
Accelerometer	Yes
Battery Capacity (internal)	950mAh
Battery Life (LP mode, 24hr reporting)	7 days
Ingress Protection	None
LED Indicators	External
Digital Inputs	6
Digital Outputs	5
ADC Inputs	2
RS232 Ports	2
CANBus	Yes
1-Wire / Dallas	1
AUX 3.3V Out	Yes
Driver ID	Yes
